Heat pumps Norwian Ecoplus 60 - 160

€4.001,75 EUR €4.302,00 EUR

Energy efficient air to water heat pumps “Norwian Ecoplus” can heat rooms and prepare hot water using significantly less energy than other heating systems.

Norwian pumps are environmentally friendly – they do not emit CO2. The R290 refrigerant used in our pumps is non-toxic, don’t have ozone-depleting properties and have a low GWP (GWP = 3 ) and is 30% more efficient than R32 refrigerant.

Model: Norwian Ecoplus 60 (1.5 - 6.27 kW)

Norwian Ecoplus 60 (1.5 - 6.27 kW)
Norwian Ecoplus 90 (2 - 9.15 kW)
Norwian Ecoplus 120 (3 - 12.2 kW)
Norwian Ecoplus 160 (4 - 16.2 kW)

Product variants

In stock

Pickup available at Lagedi

Usually ready in 5+ days

Need help?

Pairs well with

Heat pumps Norwian Ecoplus 60 - 160

Norwian Ecoplus 60 (1.5 - 6.27 kW)

€4.001,75 EUR €4.302,00 EUR

Product Details

Details

Model: Norwian Ecoplus Heat Pump

Type: Air-to-water heat pump for heating, cooling, and hot water preparation

Application: Suitable for underfloor heating,
radiators, fan coils, and hot water systems. Ideal for new construction,
renovations, and older buildings without requiring significant changes
to the existing heating system.

Refrigerant: R290 (propane) – Non-toxic, ozone-friendly, low GWP (GWP = 3), and 30% more efficient than R32 refrigerant.

Efficiency:

COP: Up to 4.67 (A7/6°C, W30/35°C)

SCOP: Up to 4.89 (A7/6°C, W30/35°C)

Energy efficiency class: A+++

Design:

Twin Rotor DC Inverter Compressor (GMCC)

Maximum supply water temperature: +75°C

Operates efficiently in outdoor temperatures as low as -25°C

Silent operation with sound pressure levels from 37 dB (at 5m distance).

Key Features:

Integrated electric heater (3 kW – 9 kW depending on the model)

Optimized pipeline design and heated compressor for reliable operation

Four-way antifreeze valve for enhanced durability

Components from leading manufacturers: Grundfos, Danfoss, GMCC

Energy Efficiency:

Reduces energy consumption with DC inverter technology

Compatible with solar power systems for enhanced sustainability

Maintains constant room temperature and extends device lifespan

Smart Features:

Equipped with a smart electronic controller with a high-resolution LCD screen

Wi-Fi compatibility via the SmartLife app for remote monitoring and control on iOS and Android devices

Online platform for remote diagnostics, fault detection, and system monitoring

Safety: Protection against freezing and overheating with smart antifreeze valves and safety designs

Maintenance: Low-maintenance design with remote monitoring capabilities for fast and efficient troubleshooting

Manufacturer: Norwian

Model info

Category	Model	Norwian Ecoplus 60	Norwian Ecoplus 90	Norwian Ecoplus 120	Norwian Ecoplus 160
Heating (A 7/6°C, W30/35°C)	Heating Capacity	1.5–6.27 kW	2–9.15 kW	3–12.2 kW	4–16.2 kW
	Power Input	1.36 kW	1.99 kW	2.61 kW	3.50 kW
	Current	5.91 A	8.83 A	4.41 A	5.89 A
	COP	4.62	4.58	4.67	4.61
	SCOP	4.71	4.89	4.77	4.77
Heating (A 7/6°C, W47/55°C)	Heating Capacity	6.06 kW	9.12 kW	12.20 kW	16.17 kW
	Power Input	2.03 kW	3.07 kW	4.03 kW	5.30 kW
	COP	2.99	2.97	3.03	3.05
	SCOP	3.71	3.72	3.73	3.75
Heating (A 7/6°C, W40/45°C)	Heating Capacity	6.12 kW	9.08 kW	12.03 kW	16.03 kW
	Power Input	1.71 kW	2.51 kW	3.30 kW	4.98 kW
	COP	3.58	3.62	3.65	3.22
Cooling (A 35/24°C, W23/18°C)	Cooling Capacity	6.3 kW	9.02 kW	11.30 kW	15.20 kW
	Power Input	1.62 kW	2.33 kW	2.91 kW	3.98 kW
	EER	3.88	3.87	3.88	3.82
Cooling (A 35/24°C, W12/7°C)	Cooling Capacity	6.2 kW	8.60 kW	10.60 kW	15.05 kW
	Power Input	2.10 kW	2.92 kW	3.58 kW	5.26 kW
	EER	2.95	2.95	2.96	2.86
General Specifications	Rated Water Flow (m³/h)	1.1 m³/h	1.6 m³/h	2.08 m³/h	2.8 m³/h
	Rated Voltage (Frequency)	220V–240V (50Hz)	220V–240V (50Hz)	380V–415V (50Hz)	380V–415V (50Hz)
	Max Input Power	2.20 kW	3.50 kW	4.70 kW	6.50 kW
	Compressor Brand/Type	GMCC/Rotary	GMCC/Rotary	GMCC/Rotary	GMCC/Rotary
	Circulation Pump	Grundfos	Grundfos	Grundfos	Grundfos
	Circulation Pump Model	UPM4 K 15-75 130	UPM4 K 15-75 130	UPM4 K 25-90130	UPM4 K 25-90130
	Plate Heat Exchanger	Danfoss	Danfoss	Danfoss	Danfoss
	E-heater	3 kW (single phase)	3 kW (single phase)	6 kW (three phase)	6 kW (three phase)
	Expansion Vessel	5 ltr	5 ltr	5 ltr	5 ltr
	Refrigerant (Type)	R290 (propane)	R290 (propane)	R290 (propane)	R290 (propane)
	Refrigerant Charge	0.55 kg	0.75 kg	1.4 kg	1.7 kg
	CO2 Equivalent (t)	0.0016 t	0.0023 t	0.0043 t	0.0051 t
	Defrosting	4-way valve	4-way valve	4-way valve	4-way valve
	Waterproof Grade	IPX4	IPX4	IPX4	IPX4
